    V680 Automatic Batch Number Printing Machine For Pipes / Wire

    Ask Lasest Price
    Brand Name : Leadjet
    Model Number : V680
    Certification : CE, ISO, SGS
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 3000 Sets/Year
    Delivery Time : Within 7 Working Days
    • Product Details
    • Company Profile

    V680 Automatic Batch Number Printing Machine For Pipes / Wire

    Leadjet V680 Automatic 1-4 Lines batch number Pipe wire coding inkjet printer


    Leadjet pipe printer and service can prolong normal operation time and improve the stability of pipe marking on extruder to a greater extent.
    Leadjet Small Character Printer has a higher level of IP protection, at the same time, it is equipped with automatic cleaning function. It can be equipped with positive pressure air system of sprinkler head to ensure cleanliness. The optimized ink system can achieve a longer stable work of typing.

    Specification

    CIJ inkjet printerV680
    Max. Print Speed280m/min(5*7 dots)
    Printable Font Height1.5mm-20mm adjustable. Maximum can be widened 9 times
    Dot Matrix25*25 dot matrix
    Memory CapacityUp to 1000 massages
    Printing linewithin 4 Lines
    Printer ContentTime, date, lot numbers, serial number etc.
    Print distance30mm Max. from printead bottom to substrate surface
    Operate InterfaceChinese,English menu, with graphic editing function
    Print Materialmetal, plastic, glass, wood, tube, electrical wire, cable etc.
    Ink colorBlack, blue, red etc
    Ink typedye-based ink
    Ink Consumption70 millions character per litre
    PowerAC220V /380V 50HZ 100AV
    Printhead Throat Length3m (customizable)
    CommunicationUSB and RS232 port
    Environment temperature5℃-45℃
    HumidityBelow 90%
    Machine Dimension248 * 338 * 550mm
    Package Size625*455*730mm
    Gross Weight40-45kg
    Display and Keyboard8-inch full-color high-definition touch screen,and full-touch virtual keyboard


    Feature
    1. Timing shutdown stop ink
    2. 8-inch full-color touch-screen control panel, stylish and easy to operate
    3. Simple appearance and easy-operate interface
    4. Multi-language design
    5. Printhead Thermostat to keep printer away from blocking
    6. Multiple filtering system to keep cleaning away
    7. Automatic cleaning system
    8. User friendly interface and most reliable ink system

    Hydraulic System
    1. Full automatic viscosity and pressure control
    2. Fully enclosed ink system
    3. Electronic control system completely separated design from hydraulic system

    Print Head
    1. Compatible design, maintenance friendly
    2. Ruby nozzle and difficult to be blocked
    3. Nozzle size: 62 μm standard, 52 to 70 μm optional
    4. Can be installed in any position
    5. Integrated design and Easily accessible

    Packaging & Shipping

    V680 Automatic Batch Number Printing Machine For Pipes / Wire

    Application

    V680 Automatic Batch Number Printing Machine For Pipes / Wire

    Company Information
    V680 Automatic Batch Number Printing Machine For Pipes / Wire

    2 QC

    2018

    Exhibition

    V680 Automatic Batch Number Printing Machine For Pipes / Wire


    FAQ
    Q:Are you factory or trading company?
    A:Founded in 1997,located in Wuhan,Leadjet is an integrated industrial and trade enterprise which has 31 branches and offices all over China.We sincerely invite you to visit our enterprise!

    Q:Is your machine avaliable to my product?
    A:Show us your product and the content you want to print on, we can print on the sample and send the video to you. And you can also deliver your sample to us, we print on the sample and deliver it back to you.The freight shall be borne by the buyer.

    Q:I have never operated inkjet printer before, is it easy to operate on?
    A:We will provide English Service Manual and you can also view our Youtube about the operating video, there is no problem for you even if you didn’t know it before.

    Q:How about the ink consumption?How long can a bottle of ink be used?
    A:It’s related to the content you print on and your daily capacity.A bottle of 700ML ink can print 10 million pieces information of 35 characters.The proportion of ink and solvent is 1:8 and the warranty of ink is 1 year. For most customers,a bottle of ink can be used for 3 months.

    Q:What if the machine is broken?
    A:We will solve your problem by three steps:
    1,Please take a video of the problem to us.
    2,Our professional after-sales engineer will test on the problem and provide you a solution.
    3,It’s avaliable to free-replace spare parts within guarantee period, and we can also provide you related videos of replacement.The freight of spare parts shall be borne by buyer.

    Q:What about your service?
    A:We offer 7*24 hours online service,please contact us.
